1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam

1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam

Dettagli:

Luogo di origine: Prodotto in Cina
Marca: EkkoFlex
Certificazione: ROSH,REACH,UL

Termini di pagamento e spedizione:

Quantità di ordine minimo: 3000 m2
Prezzo: $0.18-1.89/㎡
Imballaggi particolari: sacchetto in polipropilene o personalizzato
Tempi di consegna: 7-14 giorni lavorativi
Termini di pagamento: T/T, L/C
Capacità di alimentazione: 1000000m al mese
Miglior prezzo Contatto

Informazioni dettagliate

Nome del prodotto: 1 mm 2 mm 3 mm IXPE sottoscala Isolamento termico schiuma PE resistente agli urti Materiale: Spuma di polietilene incrociata per irradiazione
Densità: 25-300 kg/m3 Spessore: 0.5-12 mm ((unico strato) a 100 mm ((molti strati)
Struttura della cellula: Cellula vicina Vantaggi: Isolamento termico, impermeabilità e assorbimento acustico
Processo di produzione: di una lunghezza non superiore a 20 mm Larghezza: 300-1800mm
Evidenziare:

3mm IXPE Underlayment

,

2mm IXPE Underlayment

,

1mm IXPE Underlayment

Descrizione di prodotto

1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam
IXPE foam underlayment, available in various thicknesses, is a top - tier choice for SPC and WPC floors. Thicknesses ranging from 1mm to 3mm offer distinct advantages. A 1mm IXPE underlayment provides a subtle layer that enhances thermal insulation, helping to maintain a comfortable indoor temperature by reducing heat transfer through the floor. It also offers basic shock absorption, protecting floors from minor impacts.
For more significant shock resistance and cushioning, a 2 - 3mm IXPE underlayment excels. It effectively absorbs the impact of heavy footsteps, dropped items, and furniture movement, safeguarding SPC and WPC floors from scratches and dents. Additionally, the thicker layers further improve sound insulation, minimizing noise transfer between floors. Whichever thickness you choose, IXPE foam underlayment ensures enhanced durability, comfort, and performance for your SPC and WPC flooring.



1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 0



Specifications:

                                                   IXPE Foam Physical Properties
Test Item 5 Times 8 Times 10 Times 15 Times 20 Times 25 Times 30 Times 35 Times
Density(kg/m³) 200±30 125±15 100±10 66.7±8 50±6 40±4 33.3±3 28.6±2
Shore Hardness(°) >3mm thick 60-70 50-60 45-50 35-45 30-35 25-30 18-25 13-18
≤3mm thick 55-65 45-55 35-45 25-35 20-25 15-20
Tensile Strength(Mpa) TD ≥1.3 ≥0.9 ≥0.7 ≥0.5 ≥0.35 ≥0.3 ≥0.2 ≥0.15
MD ≥1.5 ≥1.0 ≥0.8 ≥0.6 ≥0.38 ≥0.35 ≥2.5 ≥0.2
Elogation(%) TD ≥200 ≥150 ≥130 ≥130 ≥130 ≥110 ≥110 ≥110
MD ≥220 ≥170 ≥150 ≥150 ≥150 ≥120 ≥120 ≥110
Tearing Strength(KN/m) TD ≥9 ≥8 ≥6 ≥4 ≥2.5 ≥2 ≥1.5 ≥1.3
MD ≥9 ≥8 ≥6 ≥4 ≥2.5 ≥2 ≥1.2 ≥1.2
Compressed Distortions(% 23℃+2℃6,22h) ≤2 ≤3 ≤5 ≤7 ≤8 ≤9 ≤10 ≤11
Dimension Change
(% 70℃+2℃,22h)
TD ≤-4 ≤-4 ≤-4 ≤-4 ≤-6 ≤-6 ≤-6 ≤-6
MD ≤-6 ≤-6 ≤-6 ≤-6 ≤-8 ≤-8 ≤-8 ≤-8
Water Absorbtion (g/cm2)23℃+2℃,24h ≤0.02 ≤0.02 ≤0.03 ≤0.03 ≤0.04 ≤0.04 ≤0.05 ≤0.05
Thermal Conductivity(w/mk) ≤0.095 ≤0.084 ≤0.073 ≤0.065 ≤0.055 ≤0.045 ≤0.040 ≤0.040







The difference between XPE foam and IXPE foam:





IXPE foam

XPE foam

Full name

Physical crosslinked polyethylene foam

                         or

Irradiation crosslinked polyethylene foam

Chemically crosslinked polyethylene foam

Production

Material PE--Extrusion--Vertical foaming--IXPE foam

Material PE--Extrusion--Horizontal foaming--XPE foam

Difference

Compared with XPE foam, IXPE foam has more delicate cellular,more smooth and flat surface,more excellent mechanical performance

Color

Black ,White,Grey and customization

Density

25-300kg/m3

Thickness

3-15mm(single layer) to 100mm(multilayer)

0.5-12mm(single layer) to 100mm(multilayer)

Material

LDPE(Low density polyethylene)

Length

No limited

Width

300-1800mm

Supplied form

Foam roll, Foam sheet, Foam block, ESD PE foam, PE foam with adhesive, PE foam with aluminum foil

Optional service

Laminating, Cutting and Adhesive coated

Application

HVAC system&Airconditioning,Packaging,

Building&construction,Sports&Leisure,

Foam tape,Floor underlayment,Medical,Sports&Leisure





1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 1





Applications:

1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 21mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 3

             Foam Camping Mat                                                       Foam Floating Mat



1mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 41mm 2mm 3mm IXPE Underlayment Thermal Insulation Shock Resistant PE Foam 5

   3D Foam Adhesive Wallpaper                                                          ESD Foam Tray





FAQ:

Q1:How can I place an order?

1)Tell us the size details and quantity you want to order.

2)We will make PI for you.

3)Checking PI and confirm it for us, we will arrange the production ASAP when the prepayment received.

4)We will take photos for you to confirm and then deliver the goods soon after the balance.

5)Send the Customs Clearance Documents or tracking number to you and track the goods for you until you get it.



Q2:How long is your production lead time?

1) Sample date will take be in 7 days

2)Mass production delivery date will be around 15-45 days,Depends on the quantity.



Q3:Is polyethylene foam toxic?
Polyethylene is Safe and Non-Toxic
Blocking chemical off-gassing is not so simple.Low density, food-grade polyethylene is safe and non-toxic. It has a simple molecular structure that does not require toxic chemical additives like phthalates and other unsafe plasticizers.
